TO-247-4

规格

Blocking Voltage(V)

1200 V

Rds(on)(mΩ)

7-1000

Tj‌(℃)

-55℃ to 175℃

认证

车规级/工业级

探索碳化硅MOSFET产品矩阵

PKG	Part Number	Blocking Voltage (V)	Rds(on) (mΩ)
TO-247-4-HC	IM120R007	1200	7
TO-247-4-HC	IM120R012	1200	12
TO-247-4-HC	IM120R017	1200	17
TO-247-4-HC	IM120R022	1200	22
TO-247-4-HC	IM120R026	1200	26
TO-247-4-HC	IM120R034	1200	34
TO-247-4-HC	IM120R040	1200	40
TO-247-4-HC	IM120R053	1200	53
TO-247-4-HC	IM120R078	1200	78
TO-247PLUS-4-HCC	IM200R012Y	2000	12
TO-247PLUS-4-HCC	IM200R024Y	2000	24
TO-247PLUS-4-HCC	IM200R050Y	2000	50
TO-247PLUS-4-HCC	IM200R075Y	2000	75
TO-247PLUS-4-HCC	AM200R100Y	2000	100
TO-247-4L	IM065R007Z	650	7
TO-247-4L	IM065R010Z	650	10
TO-247-4L	IM065R015Z	650	15
TO-247-4L	IM065R020Z	650	20
TO-247-4L	IM065R026Z	650	26
TO-247-4L	IM065R027Z	650	27
TO-247-4L	IM065R033Z	650	33
TO-247-4L	IM065R040Z	650	40
TO-247-4L	IM065R045Z	650	45
TO-247-4L	IM065R050Z	650	50
TO-247-4L	IM065R060Z	650	60
TO-247-4L	IM065R075Z	650	75
TO-247-4L	IM120R007Z	1200	7
TO-247-4L	IM120R014Z	1200	14
TO-247-4L	IM120R016Z	1200	16
TO-247-4L	IM120R020Z	1200	20
TO-247-4L	IM120R021Z-M1	1200	21
TO-247-4L	IM120R021Z-M2	1200	21
TO-247-4L	IM120R030Z	1200	30
TO-247-4L	IM120R031Z	1200	31
TO-247-4L	IM120R040Z-M1	1200	40
TO-247-4L	IM120R041Z-M2	1200	41
TO-247-4L	IM120R017Z	1200	17
TO-247-4L	IM120R041Z	1200	41
TO-247-4L	IM120R060Z	1200	60
TO-247-4L	IM120R080Z	1200	80
TO-247-4L	AM120R080Z	1200	80
TO-247-4L	IM120R090Z	1200	90
TO-247-4L	IM120R140Z	1200	140
TO-247-4L	IM120R220Z	1200	220
TO-247-4L	IM120R350Z	1200	350
TO-247-4	A4M120R010Z	1200	10
TO-247-4	A4M120R012Z	1200	12
TO-247-4	I3M120R017Z	1200	17
TO-247-4	I3M120R040Z	1200	40
TO-247-4	I4M120R017Z	1200	17
TO-247-4	A4M120R017Z	1200	17
TO-247-4	A4M120R020Z	1200	20
TO-247-4	I4M120R030Z	1200	30
TO-247-4	A4M120R030Z	1200	30
TO-247-4	I4M120R040Z	1200	40
TO-247-4	A4M120R008Z	1200	8
TO-247-4	I4M120R080Z	1200	80
TO-247-4	I4M170R028Z	1700	28
TO-247-4	I4M170R022Z	1700	22
TO-247-4	I4M170R1K0Z	1700	1000
TO-247-4	I4M170R017Z	1700	17
TO-247-4	I4M170R055Z	1700	55
TO-247-4	I4M220R030Z	2200	30
TO-247-4	I5M330R050Z	3300	50

TO-247-4

规格

探索碳化硅MOSFET产品矩阵
