碳化硅MOSFET

卓越性能与出色可靠性,达到标杆级的质量水平

奕能科技提供QDPAK、TO-247、TO-263等多种SiC MOSFET系列产品，覆盖650V、1200V、1700V、2200V等多种电压等级，综合性能卓越，可满足电动汽车、新能源、工业消费领域的多样化需求。

TO-247-4

旗舰性能，远超所望

了解更多

TO-247-3

精密工程，定义未来

了解更多

TO-263-7

驾驭高效，大有底气

了解更多

探索碳化硅MOSFET产品矩阵

PKG	Part Number	Blocking Voltage (V)	Rds(on) (mΩ)
QDPAK	IM065R007Q	650	7
QDPAK	IM065R010Q	650	10
QDPAK	IM065R015Q	650	15
QDPAK	IM065R020Q	650	20
QDPAK	IM120R012Q-H	1200	12
QDPAK	IM120R026Q-H	1200	26
QDPAK	IM120R040Q-H	1200	40
QDPAK	IM120R053Q-H	1200	53
QDPAK	IM120R078Q-H	1200	78
QDPAK	IM120R116Q-H	1200	116
QDPAK	IM120R181Q-H	1200	181
QDPAK	IM120R234Q-H	1200	234
QDPAK	IM120R004Q-Z	1200	4
QDPAK	IM120R005Q-Z	1200	5
QDPAK	IM120R007Q-Z	1200	7
QDPAK	IM120R010Q-Z	1200	10
QDPAK	IM120R017Q-Z	1200	17
QDPAK	IM120R026Q-Z	1200	26
QDPAK	IM120R034Q-Z	1200	34
QDPAK	IM120R040Q-Z	1200	40
QDPAK	IM120R053Q-Z	1200	53
QDPAK	IM120R078Q-Z	1200	78
TO-247-4-HC	IM120R007	1200	7
TO-247-4-HC	IM120R012	1200	12
TO-247-4-HC	IM120R017	1200	17
TO-247-4-HC	IM120R022	1200	22
TO-247-4-HC	IM120R026	1200	26
TO-247-4-HC	IM120R034	1200	34
TO-247-4-HC	IM120R040	1200	40
TO-247-4-HC	IM120R053	1200	53
TO-247-4-HC	IM120R078	1200	78
TO-247PLUS-4-HCC	IM200R012Y	2000	12
TO-247PLUS-4-HCC	IM200R024Y	2000	24
TO-247PLUS-4-HCC	IM200R050Y	2000	50
TO-247PLUS-4-HCC	IM200R075Y	2000	75
TO-247PLUS-4-HCC	AM200R100Y	2000	100
TO-247-3L	IM065R007W	650	7
TO-247-3L	IM065R010W	650	10
TO-247-3L	IM065R015W	650	15
TO-247-3L	IM065R020W	650	20
TO-247-3L	IM065R026W	650	26
TO-247-3L	IM065R027W	650	27
TO-247-3L	IM065R033W	650	33
TO-247-3L	IM065R040W	650	40
TO-247-3L	IM065R045W	650	45
TO-247-3L	IM065R050W	650	50
TO-247-3L	IM065R060W	650	60
TO-247-3L	IM065R075W	650	75
TO-247-3L	IM120R007W	1200	7
TO-247-3L	IM120R014W	1200	14
TO-247-3L	IM120R016W	1200	16
TO-247-3L	IM120R020W	1200	20
TO-247-3L	IM120R021W	1200	21
TO-247-3L	IM120R030W	1200	30
TO-247-3L	IM120R040W	1200	40
TO-247-3L	IM120R060W	1200	60
TO-247-3L	IM120R080W	1200	80
TO-247-3L	IM120R090W	1200	90
TO-247-3L	IM120R140W	1200	140
TO-247-3L	IM120R220W	1200	220
TO-247-3L	IM120R350W	1200	350
TO-247-3L	IM170R450W	1700	450
TO-247-3L	IM170R650W	1700	650
TO-247-3L	IM170R01KW	1700	1000
TO-247-4L	IM065R007Z	650	7
TO-247-4L	IM065R010Z	650	10
TO-247-4L	IM065R015Z	650	15
TO-247-4L	IM065R020Z	650	20
TO-247-4L	IM065R026Z	650	26
TO-247-4L	IM065R027Z	650	27
TO-247-4L	IM065R033Z	650	33
TO-247-4L	IM065R040Z	650	40
TO-247-4L	IM065R045Z	650	45
TO-247-4L	IM065R050Z	650	50
TO-247-4L	IM065R060Z	650	60
TO-247-4L	IM065R075Z	650	75
TO-247-4L	IM120R007Z	1200	7
TO-247-4L	IM120R014Z	1200	14
TO-247-4L	IM120R016Z	1200	16
TO-247-4L	IM120R020Z	1200	20
TO-247-4L	IM120R021Z-M1	1200	21
TO-247-4L	IM120R021Z-M2	1200	21
TO-247-4L	IM120R030Z	1200	30
TO-247-4L	IM120R031Z	1200	31
TO-247-4L	IM120R040Z-M1	1200	40
TO-247-4L	IM120R041Z-M2	1200	41
TO-247-4L	IM120R017Z	1200	17
TO-247-4L	IM120R041Z	1200	41
TO-247-4L	IM120R060Z	1200	60
TO-247-4L	IM120R080Z	1200	80
TO-247-4L	AM120R080Z	1200	80
TO-247-4L	IM120R090Z	1200	90
TO-247-4L	IM120R140Z	1200	140
TO-247-4L	IM120R220Z	1200	220
TO-247-4L	IM120R350Z	1200	350
TSPAK-DBC	AM120R040P	1200	40
D2PAK-7	IM065R007B	650	7
D2PAK-7	IM065R010B	650	10
D2PAK-7	IM065R015B	650	15
D2PAK-7	IM065R020B	650	20
D2PAK-7	IM065R026B	650	26
D2PAK-7	IM065R033B	650	33
D2PAK-7	IM065R040B	650	40
D2PAK-7	IM065R050B	650	50
D2PAK-7	IM065R060B	650	60
D2PAK-7	IM065R075B	650	75
TOLL	IM065R010T	650	10
TOLL	IM065R015T	650	15
TOLL	IM065R020T	650	20
TOLL	IM065R026T	650	26
TOLL	IM065R027T	650	27
TOLL	IM065R033T	650	33
TOLL	IM065R040T	650	40
TOLL	IM065R050T	650	50
TOLL	IM065R060T	650	60
TOLL	IM065R075T	650	75
TO-263-7	IM120R008B	1200	8
TO-263-7	AM120R012B	1200	12
TO-263-7	IM120R017B	1200	17
TO-263-7	IM120R022B	1200	22
TO-263-7	IM120R026B	1200	26
TO-263-7	IM120R030B	1200	30
TO-263-7	AM120R034B	1200	34
TO-263-7	IM120R040B	1200	40
TO-263-7	IM120R045B	1200	45
TO-263-7	IM120R053B	1200	53
TO-263-7	IM120R060B	1200	60
TO-263-7	IM120R078B	1200	78
TO-263-7	IM120R090B	1200	90
TO-263-7	IM120R116B	1200	116
TO-263-7	IM120R140B	1200	140
TO-263-7	IM120R181B	1200	181
TO-263-7	IM120R220B	1200	220
TO-263-7	IM120R234B	1200	234
TO-263-7	IM120R350B	1200	350
TO-263-7	IM170R450B	1700	450
TO-263-7	IM170R650B	1700	650
TO-263-7	IM170R01KB	1700	1000
TO-263-7	A4M120R020B	1200	20
TO-263-7	A4M120R030B	1200	30
TO-263-7	I4M120R040B	1200	40
TO-247-3	I4M120R080W	1200	80
TO-247-3	I5M220R050W	2200	50
TO-247-4	A4M120R010Z	1200	10
TO-247-4	A4M120R012Z	1200	12
TO-247-4	I3M120R017Z	1200	17
TO-247-4	I3M120R040Z	1200	40
TO-247-4	I4M120R017Z	1200	17
TO-247-4	A4M120R017Z	1200	17
TO-247-4	A4M120R020Z	1200	20
TO-247-4	I4M120R030Z	1200	30
TO-247-4	A4M120R030Z	1200	30
TO-247-4	I4M120R040Z	1200	40
TO-247-4	A4M120R008Z	1200	8
TO-247-4	I4M120R080Z	1200	80
TO-247-4	I4M170R028Z	1700	28
TO-247-4	I4M170R022Z	1700	22
TO-247-4	I4M170R1K0Z	1700	1000
TO-247-4	I4M170R017Z	1700	17
TO-247-4	I4M170R055Z	1700	55
TO-247-4	I4M220R030Z	2200	30
TO-247-4	I5M330R050Z	3300	50
